Custom Hoists pumps are the perfect solution to meet your high performance hydraulic system needs. They offer some the highest efficiency pumps in the industry with multiple configurations to work in tandem with our broad line of hydraulic cylinders to offer the complete solution for your hydraulic system.
PRODUCTS
Single Acting Telescopic Cylinders
Custom Hoists® single-acting telescopic cylinders feature a number of benefits to perform in today’s rigid applications. They use high-strength DOM tubing throughout the cylinder to work in applications with system pressures up to 3,000 PSI. Available to meet your specific demands are 2″ through 14.25″ plunger diameters with strokes up to 440″ and two through six moving stages. Their cylinders also have adjustable v-packing to seal high and low pressure. Threaded headnuts for extra strength and field seal adjustments, dual lip wipers to prevent contamination entry, beveled plunger stops and stop rings for plunger centering, unsurpassed lifting capacity and an easy access bleeder valve. Custom Hoists offers a variety of end mountings and either standard NPTE or SAE o-ring ports to match specific requirements.
Available on request are hard chrome plated or nitrided plungers, automatic bleeder valves and double-acting last plungers if your application requires the body to be pulled back over center. Provide eight basis specifications (application, closed length, length of stroke, base end mounting, plunger end mounting, maximum load, system working pressure and system flow GPM) and they will design a cylinder to make your job easier every day, while performing for years at a competitive price.
- European style trunnion mount
- Body Ported
- Oscillating trunnion collar reduces side loading
- D. sealed with state of the art u-cups
- Fits a variety of dump body applications
- Weighs less than most cylinders of similar design
- Chrome-plated LPA
- Optional self-aligning bearing
- Lifting capacity comparable to other brands
- Dual-lip wiper prevent contamination entry
- Fits a variety of dump body & trailer applications
- 2800 – 3500 PSI operating pressure
- Self-bleeding design
- State of the art u-cups
- Exact Euro cylinder design
- 110/130/150/170/190mm (4.33-7.48″) stage diameters
- Strokes up to 400″
- Single-piece (no welds) plungers
- Cascading umbrella wipers
- Self-bleeding design
- System pressures to 3,500 PSI
- Chrome plated stages optional
- Optional spherical bearing
- 23% more lifting capacity
- Chrome-plated plungers
- Optional nitrided plungers
- Domestically manufactured and stocked for immediate shipment
- Oscillating trunnion collar reduces side loading
- D. sealed with state of the art u-cups
- Pin Ported
- Self-bleeding design
- Pre-loaded v-packing with a self-adjusting wave spring energizer or an energized Z seal package as an option
- Threaded headnuts for added strength and field seal adjustment
- Longer bearing length for stability
- Stock models inventoried at 5 warehouse locations throughout the U.S. for immediate needs
- Trunnion to Pin Mounting
- Self-bleeding design
- Pre-loaded v-packing with a self-adjusting wave spring energizer or an energized Z seal package as an option
- Threaded headnuts for added strength and field seal adjustment
- Longer bearing length for stability
- Stock models inventoried at 5 warehouse locations throughout the U.S. for immediate needs
- Hybrid design utilizing large tube sizes with European look
- Single high performance u-cup seal with v-packing
- ‘Z’ seal option available
- Heavy duty wiper
- No seal adjustment needed
- Increased overlap between stages
- Snap-in retaining ring
- Chrome plating optional
Double Acting Telescopic Cylinders
Custom Hoists double-acting telescopic cylinders are manufactured to individual specifications to meet the rigid requirements of today’s applications, including Refuse Trucks and Solid Waste Packers, Stationary and Mobile Trash Compactors, Transfer and Push-Out Trailers, Roll-Off Units, Construction Equipment and more.
For applications that demand excellence, performance and economy, go with the best – the professionals from Custom Hoists.
Our cylinders are specifically designed to assure you the right results the first time. Call us direct and outline the requirements or discuss them with a Custom Hoists representative. We’ll take it from there. Count on us to be your exclusive cylinder source.
Custom Hoists double-acting telescopic cylinders are manufactured to individual specifications to meet the rigid requirements of today’s applications, including Refuse Trucks and Solid Waste Packers, Stationary and Mobile Trash Compactors, Transfer and Push-Out Trailers, Roll-Off Units, Construction Equipment and more.
For applications that demand excellence, performance, and economy, go with the best – the professionals from Custom Hoists.
Our cylinders are specifically designed to assure you the right results the first time. Call us direct and outline the requirements or discuss them with a Custom Hoists representative. We’ll take it from there. Count on us to be your exclusive cylinder source.
